Effect of water stress in different phases on photosynthetic characteristics of drought-avoidant soybean

doi:10.19802/j.issn.1007-9084.2021215

Abstract

Abstract:

Drought is one of the major natural disasters that limit the formation of soybean yield. Application of drought-avoidant varieties is an effective way to alleviate the loss of soybean yield under drought stress. Drought avoidance resistance refers to the ability of plants to maintain high water potential under drought stress. To better understand the mechanism of drought avoidance, two soybean hybrids with contrasting drought avoidance, Liaodou 14 （drought-avoidant） and Liaodou 21 （drought-sensitive） under water stress were evaluated, in order to reveal the photosynthetic regulation mechanism of drought-avoidant genotype soybean. The results showed that water control in each period and soil moisture significantly affected the net photosynthetic rate （Pn）, transpiration rate （Tr）, and stomatal conductance （Gs） of soybean plants. Drought limited the plant’s Pn, Tr, Gs, and intercellular CO₂concentration （Ci）. In general, the average Tr of Liaodou 21 was higher than that of Liaodou 14. With the increase in soil water content, the intercellular CO₂ concentration of plants generally gradually increased. The initial fluorescence （F₀ ） value of soil drought （W1） treatment was higher than other water treatments. The F₀ value was the lowest when the water was controlled at pod stage （R3-R5）. Drought stress reduced the maximum photochemical efficiency （Fv/Fm）, electrons transport rate （ETR） and actual photochemical efficiency （Φ_PSⅡ ） of plants. When soil moisture was controlled at the same stage, the maximum fluorescence yield （Fm） and Fv/Fm of Liaodou 14 were higher than those of Liaodou 21. On the drought stress condition, Liaodou 14 can maintain a lower transpiration rate and higher Fm and Fv/Fm value than that of Liaodou 21. This could be an important photosynthetic factor for drought-avoidant genotype to resist drought stress.

Key words: soybean, water stress, drought- avoidant variety, photosynthesis characteristics

CLC Number:

S565.1

Chun-juan YAN, Shu-hong SONG, Chang-ling WANG, Xu-gang SUN, Yong-qiang CAO, Li-jun ZHANG, Li ZHANG, Xiao-yang HUO, Wen-bin WANG. Effect of water stress in different phases on photosynthetic characteristics of drought-avoidant soybean[J]. CHINESE JOURNAL OF OIL CROP SCIENCES, 2022, 44(5): 1048-1056.

Figures/Tables 10

Table 1

Table 2

Table 3

Table 4

Table 5

Fig. 1

Fig. 2

Fig. 3

Fig. 4

Fig. 5

References 33

1	闫春娟，宋书宏，王文斌，等. 不同降雨条件对不同耐旱型大豆根系的影响［J］. 大豆科学， 2018， 37： 209-214.
2	闫春娟，宋书宏，王文斌，等. 不同耐旱型大豆根系生理生化特性对不同降雨气候条件的响应［J］. 江苏农业科学， 2018， 46（13）： 51-54. DOI：10.15889/j.issn.1002-1302.2018.13.012 . doi: 10.15889/j.issn.1002-1302.2018.13.012
3	杨阳，申双和，马绎皓，等. 干旱对作物生长的影响机制及抗旱技术的研究进展［J］. 科技通报， 2020， 36（1）： 8-15. DOI：10.13774/j.cnki.kjtb.2020.01.002 . doi: 10.13774/j.cnki.kjtb.2020.01.002
4	Hernandez-Santana V， Fernández J E， Cuevas M V， et al. Photosynthetic limitations by water deficit： Effect on fruit and olive oil yield， leaf area and trunk diameter and its potential use to control vegetative growth of super-high density olive orchards［J］. Agric Water Manag， 2017， 184： 9-18. DOI：10.1016/j.agwat.2016.12.016 . doi: 10.1016/j.agwat.2016.12.016
5	Lauteri M， Haworth M， Serraj R， et al. Photosynthetic diffusional constraints affect yield in drought stressed rice cultivars during flowering［J］. PLoS One， 2014， 9（9）： e109054. DOI：10.1371/journal.pone.0109054 . doi: 10.1371/journal.pone.0109054
6	Tang Y， Sun X， Wen T， et al. Implications of terminal oxidase function in regulation of salicylic acid on soybean seedling photosynthetic performance under water stress［J］. Plant Physiol Biochem， 2017， 112： 19-28. DOI：10.1016/j.plaphy.2016.11.016 . doi: 10.1016/j.plaphy.2016.11.016
7	Porcel R. Arbuscular mycorrhizal influence on leaf water potential， solute accumulation， and oxidative stress in soybean plants subjected to drought stress［J］. J Exp Bot， 2004， 55（403）： 1743-1750. DOI：10.1093/jxb/erh188 . doi: 10.1093/jxb/erh188
8	Cui Y， Jiang S M， Jin J L， et al. Quantitative assessment of soybean drought loss sensitivity at different growth stages based on S-shaped damage curve［J］. Agric Water Manag， 2019， 213： 821-832. DOI：10.1016/j.agwat.2018.11.020 . doi: 10.1016/j.agwat.2018.11.020
9	Specht J E， Hume D J， Kumudini S V. Soybean yield potential-A genetic and physiological perspective［J］. Crop Sci， 1999， 39（6）： 1560-1570. DOI：10.2135/cropsci1999.3961560x . doi: 10.2135/cropsci1999.3961560x
10	Meckel L， Egli D B， Phillips R E， et al. Effect of moisture stress on seed growth in soybeans 1［J］. Agronj， 1984， 76（4）： 647-650. DOI：10.2134/agronj1984.00021962007600040033x . doi: 10.2134/agronj1984.00021962007600040033x
11	刘风刚，巨鹏飞，王福政，等. 三唑酮对大豆花期干旱胁迫下根系AsA-GSH循环的影响［J］. 大豆科学， 2019， 38： 740-746.
12	Liu F， Andersen M N， Jensen C R. Loss of pod set caused by drought stress is associated with water status and ABA content of reproductive structures in soybean［J］. Funct Plant Biol， 2003， 30（3）： 271-280. DOI：10.1071/fp02185 . doi: 10.1071/fp02185
13	闫春娟，宋书宏，王文斌，等. 灌溉对不同基因型大豆生理特性及产量的影响［J］. 大豆科学， 2014， 33（6）： 945-948. DOI：10.11861/j.issn.1000-9841.2014.05.0945 . doi: 10.11861/j.issn.1000-9841.2014.05.0945
14	闫春娟，王文斌，曹永强，等. 不同耐旱型大豆生理特性对不同降雨条件的响应［J］. 大豆科学， 2018， 37： 359-365.
15	闫春娟，宋书宏，王文斌，等. 不同基因型大豆生理特性和产量对不同降雨条件的响应［J］. 节水灌溉， 2021（5）： 8-14. DOI：10.3969/j.issn.1007-4929.2021.05.002 . doi: 10.3969/j.issn.1007-4929.2021.05.002
16	Caruso A， Chefdor F， Carpin S， et al. Physiological characterization and identification of genes differentially expressed in response to drought induced by PEG 6000 in Populus canadensis leaves［J］. J Plant Physiol， 2008， 165（9）： 932-941. DOI：10.1016/j.jplph.2007.04.006 . doi: 10.1016/j.jplph.2007.04.006
17	Shweta M， Agrawal S B. Interactive effects between supplemental ultraviolet-B radiation and heavy metals on the growth and biochemical characteristics of Spinacia oleracea L［J］. Braz J Plant Physiol， 2006， 18（2）： 307-314. DOI：10.1590/s1677-04202006000200007 . doi: 10.1590/s1677-04202006000200007
18	李思，张莉，姚雅琴. 干旱对冬小麦叶片气孔、活性氧和光合作用的影响［J］. 河北大学学报（自然科学版）， 2015， 35（5）： 487-493. DOI：10.3969/j.issn.1000-1565.2015.05.008 . doi: 10.3969/j.issn.1000-1565.2015.05.008
19	刘吉利，赵长星，吴娜，等. 苗期干旱及复水对花生光合特性及水分利用效率的影响［J］. 中国农业科学， 2011， 44（3）： 469-476. DOI：10.3864/j.ssn.0578-1752.2011.03.005 . doi: 10.3864/j.ssn.0578-1752.2011.03.005
20	Abid M， Tian Z W， Ata-Ul-karim S T， et al. Improved tolerance to post-anthesis drought stress by pre-drought priming at vegetative stages in drought-tolerant and -sensitive wheat cultivars［J］. Plant Physiol Biochem， 2016， 106： 218-227. DOI：10.1016/j.plaphy.2016.05.003 . doi: 10.1016/j.plaphy.2016.05.003
21	Aghaie P， Hosseini Tafreshi S A， Ebrahimi M A， et al. Tolerance evaluation and clustering of fourteen tomato cultivars grown under mild and severe drought conditions［J］. Sci Hortic， 2018， 232： 1-12. DOI：10.1016/j.scienta.2017.12.041 . doi: 10.1016/j.scienta.2017.12.041
22	胡守林，万素梅，贾志宽，等. 黄土高原半湿润区不同生长年限苜蓿叶片光合性能研究［J］. 草业学报， 2008， 17（5）： 60-67. DOI：10.3321/j.issn： 1004-5759.2008.05.010 . doi: 10.3321/j.issn： 1004-5759.2008.05.010
23	高玉红，牛俊义，徐锐，等. 不同覆膜方式对玉米叶片光合、蒸腾及水分利用效率的影响［J］. 草业学报， 2012， 21（5）： 178-184.
24	Horton P， Ruban A V， Walters R G. Regulation of light harvesting in green plants［J］. Annu Rev Plant Physiol Plant Mol Biol， 1996， 47： 655-684. DOI：10.1146/annurev.arplant.47.1.655 . doi: 10.1146/annurev.arplant.47.1.655
25	李炳言，王娜，郝兴宇，等. 大气CO₂浓度升高和干旱的交互作用对大豆光合作用的影响［J］. 山西农业科学， 2019， 47（2）： 222-225， 258. DOI：10.3969/j.issn.1002-2481.2019.02.19 . doi: 10.3969/j.issn.1002-2481.2019.02.19
26	Hazrati S， Tahmasebi-Sarvestani Z， Modarres-Sanavy S A， et al. Effects of water stress and light intensity on chlorophyll fluorescence parameters and pigments of Aloe vera L.［J］. Plant Physiol Biochem， 2016， 106： 141-148. DOI：10.1016/j.plaphy.2016.04.046 . doi: 10.1016/j.plaphy.2016.04.046
27	Mathobo R， Marais D， Steyn J M. The effect of drought stress on yield， leaf gaseous exchange and chlorophyll fluorescence of dry beans （Phaseolus vulgaris L.）［J］. Agric Water Manag， 2017， 180： 118-125. DOI：10.1016/j.agwat.2016.11.005 . doi: 10.1016/j.agwat.2016.11.005
28	Ergo V V， Lascano R， Vega C R C， et al. Heat and water stressed field-grown soybean： a multivariate study on the relationship between physiological-biochemical traits and yield［J］. Environ Exp Bot， 2018， 148： 1-11. DOI：10.1016/j.envexpbot.2017.12.023 . doi: 10.1016/j.envexpbot.2017.12.023
29	Li J H， Cang Z M， Jiao F， et al. Influence of drought stress on photosynthetic characteristics and protective enzymes of potato at seedling stage［J］. J Saudi Soc Agric Sci， 2017， 16（1）： 82-88. DOI：10.1016/j.jssas.2015.03.001 . doi: 10.1016/j.jssas.2015.03.001
30	Peeva V， Cornic G. Leaf photosynthesis of Haberlea rhodopensis before and during drought［J］. Environ Exp Bot， 2009， 65（2/3）： 310-318. DOI：10.1016/j.envexpbot.2008.09.009 . doi: 10.1016/j.envexpbot.2008.09.009
31	Ben Abdallah M， Trupiano D， Polzella A， et al. Unraveling physiological， biochemical and molecular mechanisms involved in olive （Olea europaea L. cv. Chétoui） tolerance to drought and salt stresses［J］. J Plant Physiol， 2018， 220： 83-95. DOI：10.1016/j.jplph.2017.10.009 . doi: 10.1016/j.jplph.2017.10.009
32	Dias M C， Correia S， Serôdio J， et al. Chlorophyll fluorescence and oxidative stress endpoints to discriminate olive cultivars tolerance to drought and heat episodes［J］. Sci Hortic， 2018， 231： 31-35. DOI：10.1016/j.scienta.2017.12.007 . doi: 10.1016/j.scienta.2017.12.007
33	López-Jurado J， Balao F， Mateos-Naranjo E. Deciphering the ecophysiological traits involved during water stress acclimation and recovery of the threatened wild carnation， Dianthus inoxianus ［J］. Plant Physiol Biochem， 2016， 109： 397-405. DOI：10.1016/j.plaphy.2016.10.023 . doi: 10.1016/j.plaphy.2016.10.023

品种 Variety	水分 Water	控水时期 Stage of water controlled
品种 Variety	水分 Water	营养生长期 Seedling stage （V4-R1）	花期 Flowering stage （R1-R3）	结荚期 Podding stage （R3-R5）	鼓粒期 Pod filling stage （R5-R6）
辽豆14 Liaodou 14	W1	5.18 ^Cc	5.02^Bc	5.05 ^Cc	11.77 ^Cc
	W2	8.67 ^Bb	11.32^Bb	12.45^Bb	13.80 ^Cc
	W3	12.79 ^Aa	23.39^Aa	22.12^Aa	26.15^Aa
辽豆21 Liaodou 21	W1	4.78 ^Cc	4.87^Bc	4.25 ^Cc	13.99 ^Cc
	W2	9.35 ^Bb	11.63^Bb	16.98^ABb	15.32^BCc
	W3	12.48 ^Aa	27.77^Aa	22.25^Aa	20.19^Bb
平均值Mean
辽豆14 Liaodou 14		8.88 ^Aa	13.25^Aa	13.21^Aa	17.24^Aa
辽豆21 Liaodou 21		8.87 ^Aa	14.75^Aa	14.49^Aa	16.50^Bb
W1		4.98 ^Cc	4.95 ^Cc	4.65^Bc	12.88 ^Bb
W2		9.01 ^Bb	11.47 ^Bb	14.72^Ab	14.56^ABb
W3		12.64^Aa	25.58^Aa	22.19^Aa	23.17^Aa
方差分析（ANOVA）
品种 Varieties		ns	ns	ns	*
水 Water		***	*	*	***
品种×水 V×W		ns	ns	ns	ns

品种 Variety	水分 Water	控水时期 Stage of water controlled
品种 Variety	水分 Water	营养生长期 Seedling stage （V4-R1）	花期 Flowering stage （R1-R3）	结荚期 Podding stage （R3-R5）	鼓粒期 Pod filling stage （R5-R6）
辽豆14 Liaodou 14	W1	2.24 ^Bc	2.39^Bb	2.08 ^Cd	2.02 ^Dc
	W2	3.52 ^Ab	5.03^Bb	6.08 ^ABCbc	2.66 ^CDc
	W3	4.76 ^Aa	13.98 ^Aa	7.38 ^ABab	7.19 ^Aa
辽豆21 Liaodou 21	W1	1.96 ^Bc	2.50^Bb	4.24 ^BCcd	2.75 ^CDc
	W2	3.99 ^Aab	5.76^Bb	5.61 ^ABCbc	4.4B ^Cb
	W3	4.55 ^Aa	13.16 ^Aa	9.02 ^Aa	5.81 ^ABab
平均值 Mean
辽豆14 Liaodou 14		3.51 ^Aa	7.13 ^Aa	5.18^Ab	3.95^Ab
辽豆21 Liaodou 21		3.72 ^Aa	7.14 ^Aa	6.29 ^Aa	4.32^Aa
W1		2.10 ^Cc	2.45^Bc	3.16^Bc	2.38^Bc
W2		3.76 ^Bb	5.39^Bb	5.85 ^Ab	3.53^Bb
W3		4.65^Aa	13.57 ^Aa	8.20 ^Aa	6.50^Aa
方差分析（ANOVA）
品种 Varieties		ns	ns	*	*
水 Water		***	***	***	***
品种×水 V×W		ns	ns	ns	ns

品种 Variety	水分 Water	控水时期 Stage of water controlled
品种 Variety	水分 Water	营养生长期 Seedling stage （V4-R1）	花期 Flowering stage （R1-R3）	结荚期 Podding stage （R3-R5）	鼓粒期 Pod filling stage （R5-R6）
辽豆14 Liaodou 14	W1	59.17^Bb	62.49^Bb	40.03 ^Cc	80.00 ^Cd
	W2	94.36 ^ABb	133.91^Bb	81.52 ^BCc	114.57^Ccd
	W3	200.48^Aa	451.11^Aa	290.09 ^Aa	366.24^Aa
辽豆21 Liaodou 21	W1	49.55^Bb	63.40^Bb	49.00^Cc	115.21^Ccd
	W2	109.24^ABab	159.47^Bb	183.93 ^ABb	193.14^BCc
	W3	123.46^ABab	411.80^Aa	266.26 ^Aab	274.24^ABb
平均值（means）
辽豆14 Liaodou 14		118.01^Aa	215.84^Aa	137.21^Aa	186.94^Aa
辽豆21 Liaodou 21		94.08^Aa	211.55^Aa	166.39^Aa	194.20^Aa
W1		54.36 ^Bb	62.94^Bb	44.51^Bc	97.61^Bc
W2		101.80 ^ABab	146.69^Bb	132.73^Bb	153.86^Bb
W3		161.97 ^Aa	431.46^Aa	278.17^Aa	320.24^Aa
方差分析（ANOVA）
品种 Varieties		ns	ns	ns	ns
水 Water		*	***	***	***
品种×水 V×W		ns	ns	ns	*

品种 Variety	水分 Water	控水时期 Stage of water controlled
品种 Variety	水分 Water	营养生长期 Seedling stage （V4-R1）	花期 Flowering stage （R1-R3）	结荚期 Podding stage （R3-R5）	鼓粒期 Pod filling stage （R5-R6）
辽豆14 Liaodou 14	W1	229.21^Aa	105.8 ^Cc	97.56^Bb	128.00 ^Cb
	W2	216.32^Aa	115.59 ^ABab	112.34^Bb	156.80 ^BCb
	W3	238.45^Aa	106.98 ^Cc	238.76^Aa	244.69 ^Aa
辽豆21 Liaodou 21	W1	209.88^Aa	115.9 ^ABab	119.46^Bb	168.42 ^ABCb
	W2	221.02^Aa	112.66 ^Bb	208.07^Aa	230.34 ^ABa
	W3	198.34^Aa	118.39 ^Aa	222.93^Aa	239.85 ^ABa
平均值 Mean
辽豆14 Liaodou 14		227.99^Aa	109.46 ^Bb	149.55 ^Bb	176.50 ^Ab
辽豆21 Liaodou 21		209.75^Aa	115.65 ^Aa	183.49 ^Aa	212.87 ^Aa
W1		219.54^Aa	110.85^Ab	108.51 ^Cc	148.21 ^Bc
W2		218.67^Aa	114.13^Aa	160.20 ^Bb	193.57 ^ABb
W3		218.40^Aa	112.69 ^Aab	230.85 ^Aa	242.27 ^Aa
方差分析（ANOVA）
品种 Varieties		ns	***	*	*
水 Water		ns	*	***	**
品种×水 V×W		ns	***	*	ns

指标 Index	营养生长期控水 Water controlled at seedling stage （V4-R1）			花期控水 Water controlled at flowering stage （R1-R3）			结荚期控水 Water controlled at podding stage（R3-R5）			鼓粒期控水 Water controlled at pod filling stage （R5-R6）
指标 Index	Pn	Tr	Gs	Pn	Tr	Gs	Pn	Tr	Gs	Pn	Tr	Gs
Tr	0.93^**			0.98^**			0.90^**			0.97^**
Gs	0.90^**	1.00^**		0.97^**	1.00^**		0.96^**	0.85^*		0.98^**	1.00^**
Ci	0.01	0.34	0.40	0.20	0.05	0.02	0.92^**	0.79^*	0.97^**	0.82^*	0.93^**	0.90^**
